Arched double door with reeded glass and classic panels
A tall double door set in a round-top opening. Each leaf stacks a raised classic panel at the bottom, a fluted wood panel in the middle and reeded glass at the top, following the curve of the arch. A casing frames the whole opening, arch included.
Details
- Semicircular (round-top) opening
- Two leaves
- Reeded glass that follows the arch
- Fluted wood mid panel
- Raised panels with a classic stepped molding
- Casing that follows the opening and the arch
As modeled
| Type | Door |
|---|---|
| Opening, as modeled | 68.1 × 100.4 in (173 × 255 cm) |
| Leaves | 2 |
| Units in the editor | Inches or centimetres |
Adjustable in 3D
- Opening: width, height and wall thickness
- Casing: width and projection
- Leaf: thickness, stiles, top and bottom rails, gap
- Panels: molding width and bevel width
- Overall relief of the moldings
Fits
TraditionalParisian / HaussmannMediterranean
3D model · drag to rotate, scroll to zoom
Loading the 3D model…
1 · Look around
Rotate the model, zoom in on the moldings and switch between the photo view, front and side.
2 · Adjust it
Change the opening, the casing, the leaf and the panels with the sliders, in inches or centimetres.
3 · Use it in a plan
In Vizion Floorplan, select a door on your plan and pick this model from the Vizion library. The opening sets the width and height.
